Blast Resistant Doors

  • NEW! 3’0″x7’0″ custom (not stock) honeycomb core door now approved for 4 psi blast-resistant rating
  • This feature provided at no charge as a standard feature of custom honeycomb door
  • Continuously welded vertical edges (seamless) standard
  • Tested for 3’0″x7’0″ custom honeycomb core door; other sizes may be available depending on engineering evaluation or additional tests. (ask sales consultant)
  • 1 3/ 4” door thickness only
  • Requires 18-gauge galvannealed steel
  • Rust inhibitive prime coat ANSI/SDI 250.10
  • This door has passed the 10 million cycle test

Material Options

  • Honeycomb core

Feature Options

  • Up to 3-hour fire label
  • Flush top cap
  • Commercial Grade 1 lockset required (by others)
  • Lites and louvers are not supported

Hardware Reinforcements

  • 3/16” hinge reinforcements
  • Commercial grade hinges required (by others)

Test Information

  • GSA TS-01 Level C (peak pressure / impulse = 4 psi / 28 psi-msec)
  • Door/frame was tested to ASTM F2927-12 standards
